Industrial Fiber Media Converter 10/100/1000M with 2 RJ45 port Singlemode SMF Duplex SC 1310nm 20KM

Brand Name : GoreLink

Model Number : GL-IM03-220SC

Certification : CE,RoHS

Place of Origin : China

MOQ : 1pc

Payment Terms : T/T, Western Union,Paypal

Delivery Time : 1-3 Working days

Packaging Details : 1pcs/box

Product : Industrial Ethernet to Fiber Media Converter

Application : FTTH FTTB FTTX Network

Part Number : GL-IM03-220SC

Data rate : 10/100/1000Mbp

Fiber Ports : 1 Port

Fiber Connector : SC

RJ45 Ports : 1 Port

Fiber Mode : SMF/Duplex

Working : Auto-negotiation

Transmission distance : 20KM

Wavelength : 1310nm

Material : Aluminum Alloy

Mounting Way : DIN Rail bracket mounting

Operating temperature : -20 ~ 85°C

Storage Temperature : - 40 ~ 85℃

Contact Now

10/100/1000TX to 1000FX Industrial Fiber Media Converter,Singlemode Duplex/SMF,1xSC, 1xRJ45,1310nm,SC,20KM,DIN Rail Mounting

This Industrial fiber media converter is a specialized device designed to convert network signals between copper Ethernet and fiber optics in industrial environments. It is Specially designed for harsh outdoor applications. These environments often have harsher conditions, such as extreme temperatures, humidity, vibrations, and electrical interference, requiring robust and reliable equipment. These Series consist of Multimode and Single-mode versions with optics supporting up to 80 kilometers over Single mode for long-haul industrial ethernet media converter applications. Each unit is powered by an external 24V DC Industrial Power Supply. Its 4KV network port surge protection can adapt to harsh outdoor environments and ensure the reliability of the uninterrupted system.

Application

  • CCTV Networks

  • Apply to Urban Intelligent Traffic Monitoring System (ITS)

  • Fiber network system

  • Automation

  • Local Area Networks

What is the Key Features of Industrial Fiber Media Converters:

  • Rugged Design to withstand harsh conditions.
  • Shock and Vibration Resistance
  • Wide Operating Temperature Range from -40°C to +75°C
  • Supports DC power input, often with wide voltage ranges (e.g., 12–48V DC).
  • Environmental Protection with IP Rating IP40.
  • EMI/RFI Immunity: Designed to resist electromagnetic and radio frequency interference.
  • Supports single-mode or multi-mode fiber with various connectors (e.g., LC, SC, ST).
  • Ethernet ports usually support 10/100/1000 Mbps speeds.
  • DIN Rail or Wall Mounting
  • Redundancy and Reliability to ensure consistent network uptime.
  • Link Fault Pass-Through (LFP) helps identify and isolate faults in the network.

Advantages of Industrial Fiber Media Converters

  • Reliability: Designed for uninterrupted operation in challenging conditions.
  • Longevity: High durability reduces maintenance and replacement costs.
  • Flexibility: Supports diverse network types and configurations.
  • Safety: Withstand electrical surges and hazardous conditions

General Specification

Product

Industrial Gigabit Ethernet to Fiber Media Converter

Protocol Type

10/100/1000BaseT(X) to 1000BaseFX

Media

Singlemode SMF/Duplex

Fiber Interface

1x SC port

Ethernet Port

1x 10/100/1000BaseT(X) RJ45

Wavelength

1310nm

Transmission Distance

20KM

Power Connector

Terminal Block

Operation temperature

-20 to 85°C

Storage Temperature

-40 to 85°C

Relative Humidity

5% to 95%

Physical Characteristics

Housing

Aluminun alloy case

Dimension(mm)

118(L) * 86 (W)*34(H)mm

Color

Black

IP Rated

IP40

Installation

DIN Rail mounting

Warranty

5 Years

Compliance

IEEE802.3 10BASE-T; IEEE802.3i 10Base-T;IEEE802.3u;100Base-T

X/FX; IEEE802.3ab 1000Base-T; IEEE802.3z 1000Base-X; IEEE8023x

Industrial Fiber Media Converter 10/100/1000M with 2 RJ45 port Singlemode SMF Duplex SC 1310nm 20KM

Ordering Information

PART NO.

DESCRIPTION

GL-IM03-220SC

Gorelink 10/100/1000TX to 1000FX Industrial Fiber Media Converter,Singlemode Duplex/SMF,1xSC, 1xRJ45,1310nm,20KM,DIN Rail Mounting

GL-IM03-240SC

Gorelink 10/100/1000TX to 1000FX Industrial Fiber Media Converter,Singlemode Duplex/SMF,1xSC, 1xRJ45,1310nm,40KM,DIN Rail Mounting

GL-IM03-260SC

Gorelink 10/100/1000TX to 1000FX Industrial Fiber Media Converter,Singlemode Duplex/SMF,1xSC, 1xRJ45,1310nm,60KM,DIN Rail Mounting

GL-IM03-280SC

Gorelink 10/100/1000TX to 1000FX Industrial Fiber Media Converter,Singlemode Duplex/SMF,1xSC, 1xRJ45,1550nm,80KM,DIN Rail Mounting

* Customized
